Stonex SC650 S CORS GNSS Receiver
The SC650 S is the high-update-rate variant of Stonex's flagship CORS receiver, powered by a Septentrio 440+ channel board and optimized for applications where real-time responsiveness is critical. Running at a 100Hz position rate, it is purpose-built for machine control, structural monitoring, and real-time navigation where fast, continuous data streams are essential. Like its counterpart, it supports all major satellite constellations including GPS, GLONASS, Galileo, BeiDou, QZSS, and IRNSS, with advanced multipath mitigation and interference rejection for reliable performance in challenging signal environments. A dual-band UHF radio, 4G LTE, Wi-Fi, and Bluetooth ensure flexible connectivity for any deployment scenario, while the Linux-based Web UI enables full remote configuration and monitoring from any device. With versatile I/O ports including DB9, Ethernet, and M12, the SC650 S integrates effortlessly into existing infrastructure, and its IP68 rating with 1.5-meter drop resistance ensures it holds up wherever it's deployed.
Specifications:
- GNSS Board: Septentrio, 440+ channels
- Position Rate: 100Hz
- Satellite Systems: GPS, GLONASS, Galileo, BeiDou, QZSS, IRNSS
- UHF Radio: Dual-band, 410-470 MHz and 902.4-928 MHz
- Connectivity: 4G LTE, Wi-Fi, Bluetooth, Ethernet, DB9, M12
- Data Storage: 32 GB
- Waterproof Rating: IP68
- Operating Temperature: -40°C to +80°C
- Weight: 570g
